The self clean automatic ballast water filter is designed for continuous filtration of water in pressurized systems. River water back-flush automatic filter removes debris and particles from natural water sources such as sea water or river water.
Material: Duplex stainless steel 2205, SS904L
Structure: 4-layer sintered mesh Perforated plate
Filtering range: 1-1000 micr
Size: according to customer specified size
Diameter tolerance r: ± 0.5mm
Self Clean Automatic Ballast Water Filter
The self clean automatic ballast water filter is designed for continuous filtration of water in pressurized systems. River water back-flush automatic filter removes debris and particles from natural water sources such as sea water or river water.
The filter element of self clean automatic ballast water filter is cleaned by the cleaning disc mounted on the pneumatic cylinder rod. When the cleaning action triggered, the disc moves into the automatic filter element and water passes through the gap between the disc and the filter element. Flow velocity increases around the disc and the static pressure around the disc decreases because of the Bernoulli principle. Around the disc edge, the vacuum effect of lower static pressure makes the filtered water back-flush the filter element surface.
